Any electricians in the Lounge?
2
Jun 4, 2025, 6:51 AM
|
|
If so, have a question..
My range/stove would turn on, poweer up but would not heat up. The burners nor oven would get hot but the range would turn on. I thought it was the range so I bought a new one. Had the new range installed, with a new plug. Same thing., It turns on, lights up but the burners and oven don't get warm.
Going to hire an electrician i guess. However, has anyone had this happen to them?
|
|
|
|
 |
Ultimate Clemson Legend [104008]
TigerPulse: 100%
64
Posts: 29336
Joined: 2014
|
P=IV***
2
Jun 4, 2025, 7:34 AM
|
|
|
|
|
|
|
|
Ultimate Clemson Legend [103082]
TigerPulse: 100%
64
Posts: 99031
Joined: 2009
|
This is a strange problem.
2
Jun 4, 2025, 7:37 AM
|
|
I've never seen this.
Swap the breaker which powers the stove. It's easy to swap. Cut the main breaker, remove the breaker which serves the range, unscrew the wires and put them on the new beaker. Make dang sure the wires securely fastened to that breaker then snap it back in place.
If you're nervous pull the meter and the main breaker.
|
|
|
|
|
|
Ultimate Tiger [35200]
TigerPulse: 100%
56
Posts: 39313
Joined: 2003
|
Assume you've got a 240V plug/connection...
9
9
Jun 4, 2025, 7:50 AM
|
|
sounds like one of your hot legs is dead. Could be a wiring issue, a breaker issue, or a plug issue. Sounds like you changed something with a different plug, so likely something at the outlet or breaker.
Some of the functions of your unit run on 120V and some on 240V. 120V is one hot leg to the neutral and 240V is one hot leg to the other hot leg. So one hot leg being dead could explain your problem.
Household 240V breakers are normally 2 x 120V breakers tied together. Make sure one side of that breaker hasn't tripped and/or cycle that breaker off and back on.
If you have a multi-meter, check the voltage between the hot legs (should be about 240V) and from each hot leg to the neutral (should be about 120V).
If you detect an issue, turn off the breaker...check that there is no voltage on the outlet and remove the outlet cover and check to make sure there are no loose wires.
With all that said, since you're asking this question...probably better call an electrician.
|
|
|
|
|
|
All-Time Great [88823]
TigerPulse: 100%
63
Posts: 48396
Joined: 2007
|
^^^ what flow said.***
1
Jun 4, 2025, 7:53 AM
|
|
|
|
|
|
|
|
National Champion [7767]
TigerPulse: 100%
42
Posts: 16320
Joined: 2002
|
|
|
|
|
|
Ultimate Clemson Legend [103082]
TigerPulse: 100%
64
Posts: 99031
Joined: 2009
|
So just swap out the breaker?
1
Jun 4, 2025, 9:34 AM
[ in reply to Assume you've got a 240V plug/connection... ] |
|
One seldom sees a two separate breakers serving a dedicated circuit. I haven't seen one is 30 years and that was old wiring.
|
|
|
|
|
|
All-Time Great [88823]
TigerPulse: 100%
63
Posts: 48396
Joined: 2007
|
It's most likely a 2 pole breaker and not two 1 pole breakers tied together.***
1
Jun 4, 2025, 9:36 AM
|
|
|
|
|
|
|
|
Ultimate Tiger [35200]
TigerPulse: 100%
56
Posts: 39313
Joined: 2003
|
|
|
|
|
|
All-Time Great [88823]
TigerPulse: 100%
63
Posts: 48396
Joined: 2007
|
I'm aware, I was responding to CT1988's post.
Jun 4, 2025, 3:32 PM
|
|
Where I have indeed seen two separate 1P breakers used in that fashion.
|
|
|
|
|
|
Ultimate Tiger [35200]
TigerPulse: 100%
56
Posts: 39313
Joined: 2003
|
Are you looking for a fight?....
1
Jun 4, 2025, 4:00 PM
|
|
|
|
|
|
|
|
Clemson Sports Icon [58275]
TigerPulse: 100%
59
Posts: 24053
Joined: 1998
|
Re: Are you looking for a fight?....
3
Jun 4, 2025, 4:05 PM
|
|
|
|
|
|
|
|
All-Time Great [88823]
TigerPulse: 100%
63
Posts: 48396
Joined: 2007
|
Not at all, your original post answer was a thing of masterpiece.
Jun 4, 2025, 4:07 PM
[ in reply to Are you looking for a fight?.... ] |
|
I don't think I could've explained it that well.
|
|
|
|
|
|
National Champion [7767]
TigerPulse: 100%
42
Posts: 16320
Joined: 2002
|
It is rarely a bad breaker.
Jun 4, 2025, 9:51 AM
[ in reply to So just swap out the breaker? ] |
|
My guess is either a bad leg on the wiring, or incorrect connection to the 50A receptacle.
|
|
|
|
|
|
All-Time Great [90960]
TigerPulse: 100%
63
Posts: 62494
Joined: 2004
|
I have seen more breaker problems in the last 5 years
1
Jun 4, 2025, 11:13 AM
|
|
than I ever have in my life. I've had two breakers randomly start trippin' in my last house, replaced them and the circuits were fine.
I'm not even going to start with GFCI breakers. There's about a 30% chance a new one will be bad.
|
|
|
|
|
|
National Champion [7767]
TigerPulse: 100%
42
Posts: 16320
Joined: 2002
|
Re: I have seen more breaker problems in the last 5 years
1
Jun 4, 2025, 11:16 AM
|
|
GFCI breakers are the worst.
|
|
|
|
|
|
National Champion [7767]
TigerPulse: 100%
42
Posts: 16320
Joined: 2002
|
Re: I have seen more breaker problems in the last 5 years
1
Jun 4, 2025, 11:17 AM
|
|
But not nearly as annoying as arc fault breakers.
|
|
|
|
|
|
All-Time Great [90960]
TigerPulse: 100%
63
Posts: 62494
Joined: 2004
|
I don't have any of those, thank goodness.
1
Jun 4, 2025, 11:23 AM
|
|
It seems like nothing is being made 'like it used to be".
|
|
|
|
|
|
Ultimate Clemson Legend [104008]
TigerPulse: 100%
64
Posts: 29336
Joined: 2014
|
|
|
|
|
|
Orange Elite [5388]
TigerPulse: 100%
38
|
|
|
|
|
|
Orange Immortal [67115]
TigerPulse: 100%
60
Posts: 15643
Joined: 2018
|
I'd get another range.***
2
Jun 4, 2025, 7:58 AM
|
|
|
|
|
|
|
|
Heisman Winner [86544]
TigerPulse: 100%
62
Posts: 39126
Joined: 2003
|
They just don't make 'em like they used to, I guess.
2
Jun 4, 2025, 8:02 AM
|
|
|
|
|
|
|
|
Ultimate Tiger [35209]
TigerPulse: 100%
56
|
Re: I'd get another range.***
3
Jun 4, 2025, 8:03 AM
[ in reply to I'd get another range.*** ] |
|
I bought a brand new one and it is doing the same thing.
|
|
|
|
|
|
Orange Immortal [67115]
TigerPulse: 100%
60
Posts: 15643
Joined: 2018
|
Third time's the charm, as they say in the range business.
7
7
Jun 4, 2025, 8:05 AM
|
|
Of course it might be a good idea to listen to Flow and call the electrician.
|
|
|
|
|
|
Heisman Winner [81245]
TigerPulse: 100%
62
Posts: 28425
Joined: 2014
|
It's called Range-onomics
5
5
Jun 4, 2025, 8:55 AM
[ in reply to Re: I'd get another range.*** ] |
|
and it's mainly supply-side, you got to keep buying one until it works
|
|
|
|
|
|
Clemson Sports Icon [56139]
TigerPulse: 100%
59
Posts: 21808
Joined: 2014
|
Probably a dumb question on my part. But
1
Jun 4, 2025, 8:07 AM
|
|
Is it a glass top with electric heating elements or is it possibly an induction stovetop?
|
|
|
|
|
|
Ultimate Tiger [35209]
TigerPulse: 100%
56
|
Re: Probably a dumb question on my part. But
1
Jun 4, 2025, 8:11 AM
|
|
Glass top with electric heating elements.
|
|
|
|
|
|
Clemson Sports Icon [56139]
TigerPulse: 100%
59
Posts: 21808
Joined: 2014
|
Just making sure.
2
Jun 4, 2025, 8:16 AM
|
|
I’ve heard of people buying induction cooktops and not having pans suitable for induction tops, then not understanding why it’s not getting hot.
Flow has the correct answer.
|
|
|
|
|
|
National Champion [7767]
TigerPulse: 100%
42
Posts: 16320
Joined: 2002
|
Re: Any electricians in the Lounge?
1
Jun 4, 2025, 8:46 AM
|
|
Sounds like you have lost a leg of the 50A 2 pole breaker, and are only getting 120V to the range. So it's either a bad breaker, or bad #8awg wiring between the receptacle and the breaker.
|
|
|
|
|
|
Tiger Titan [48747]
TigerPulse: 100%
58
Posts: 19971
Joined: 2015
|
Simple fix here. Pull it out away from the wall. Usually on the back side to
3
Jun 4, 2025, 9:23 AM
|
|
your left as you are facing it from the rear, you'll have a heat overflow/reserve cannister. Just top it up with more heat and you are good to go.
What happens here is when that reservoir depletes the heat intended for your unit is redirected to that reservior instead of the stove top or whatevs.
You can get more heat from just about any hardware store. YWIA!
|
|
|
|
|
|
Orange Immortal [67115]
TigerPulse: 100%
60
Posts: 15643
Joined: 2018
|
Solid advice. It will probably look something like this:
1
Jun 4, 2025, 9:33 AM
|
|
|
|
|
|
|
|
Tiger Titan [48747]
TigerPulse: 100%
58
Posts: 19971
Joined: 2015
|
That's it. Sorta. That's a free standing unit normally fit for
2
Jun 4, 2025, 10:22 AM
|
|
commercial use.
OP's won't be on wheels, rather it will slide into a sleeve attached to the rear of the stove.
Thanks Ken for providing the visual that I was too GD lazy to provide.
|
|
|
|
|
|
Ring of Honor [22348]
TigerPulse: 100%
53
Posts: 17623
Joined: 1998
|
|
|
|
|
|
Clemson Sports Icon [53033]
TigerPulse: 100%
59
Posts: 33574
Joined: 2015
|
Step one: Take off your shoes, lick your fingers good then
1
Jun 4, 2025, 11:51 AM
|
|
touch one side of the breaker at a time. If you get a good jolt from each side, you know it's not the breaker
120 isn't that bad but 240 will #### you up. So make sure it's only one side at a time
|
|
|
|
|
|
Clemson Sports Icon [52976]
TigerPulse: 100%
59
Posts: 32771
Joined: 1999
|
All I Know: Volts shock you, Amps kill you
Jun 4, 2025, 11:53 AM
|
|
HTH
|
|
|
|
|
|
